Comparison of characteristics between modular UPS and tower UPS
Time of issue:2023-05-15
Views:
Modular UPS has many advantages compared to traditional tower UPS, but in different regions and industries, there are some controversies due to different cognitions. This article will not make too many comparisons. Only the relevant features are compared as follows. The investment comparison is for reference only. The prices of products of different manufacturers are different, and the actual situation shall prevail.
|
|
Items |
Tower UPS |
Modular UPS |
Modular UPS of INVT Power |
|
Grid-connected reliability |
Hardware design |
Power controller integrated parallel control |
Power controller + parallel controller |
Isolated cold air channel design + PCB board three-proof spraying process |
|
Logical design |
Master-slave competition redundancy，Complex logic |
Master-slave competition redundancy or centralized control |
Adopt non-master-slave distributed control logic mode |
|
|
Communication |
Single CAN or double CAN |
Single CAN or double CAN |
double CAN redundancy |
|
|
Reliability evaluation |
êêêê |
êêêê |
êêêêê |
|
|
Power unit reliability |
Voltage loop |
Module independent control |
Module independent control |
Module independent control |
|
Current loop |
Analog control/digital control |
Fully digital control |
Fully digital control |
|
|
Components |
Few redundant design |
Partially redundant design |
Using integrated package IGBT module device |
|
|
Reliability evaluation |
êêê |
êêêê |
êêêêê |
|
|
Bypass unit reliability |
Parallel bypass mode |
Decentralized bypass |
Parallel in the rack: centralized bypass Parallel between racks: decentralized bypass |
Parallel in the rack: centralized bypass |
|
Reliability evaluation |
êêêê |
êêêê |
êêêêê |
|
|
Power unit failure impact |
Range |
If a unit is broken, the whole system is missing, and the power loss is large |
A broken module only affects a single module, and the power loss is small |
A broken module only affects a single module, and the power loss is small |
|
Reliability evaluation |
êêêê |
êêêêê |
êêêêê |
|
|
Overall reliability evaluation |
êêêê |
êêêê |
êêêêêê |
|
|
|
Items |
Tower UPS |
Modular UPS |
Modular UPS of INVT Power |
|
Installation and transportation |
Volume and weight |
Big |
Small |
Small |
|
Transportation |
Part of the UPS system can be transported separately |
The cabinet and the module can be transported individually |
The cabinet and the module can be transported individually, also support integrated transportation |
|
|
Expansion |
Equivalent to demolishing and reconfiguring |
Easily expand capacity and invest in installments |
Easily expand capacity and invest in installments |
|
|
User-friendly evaluation |
êêêê |
êêêêê |
êêêêê |
|
|
Use |
Monitor |
Have basic monitoring capabilities |
Have basic monitoring capabilities |
Strong monitoring function |
|
Battery |
Very few can be used together |
Some can be used together |
All can be used together |
|
|
User-friendly evaluation |
êêêê |
êêêê |
êêêêê |
|
|
Maintenance |
Maintenance |
Need to remove cables and internal structure, maintenance time is long, similar to modular detachable module maintenance. |
Power module online hot-swap replacement |
Online hot-swap of monitoring module, bypass module, and power module |
|
User-friendly evaluation |
êêê |
êêêê |
êêêêê |
|
|
Overall user-friendly evaluation |
êêê |
êêêê |
êêêêêê |
|
|
|
Items |
Tower UPS |
Modular UPS |
Modular UPS of INVT Power |
|
Equipment |
UPS |
UPS system parallel redundancy，Wide power range，Moderate cost |
Power module parallel redundant power is low, and has a Medium cost |
The power module ranges from 10 to 50KVA, there are 7 kinds of power modules for selection, and the main cabinet has more than 13 kinds for selection, and the configuration is flexible. Choose the most reasonable configuration and save the overall investment |
|
Battery |
Very few can be used together. High configuration |
Some can be used together. Flexible configuration and low cost |
All can be used together，Flexible configuration of 32-44 batteries |
|
|
Investment evaluation |
êêêê |
êêêêê |
êêêêê |
|
|
Installation and transportation |
Volume and weight |
Big, High cost of land lease and load-bearing parts |
Small |
Small |
|
Transportation |
Sometimes the infrastructure of the computer room needs to be changed, which is expensive |
The cabinet and the module can be transported individually |
The cabinet and the module can be transported individually |
|
|
Expansion |
Equivalent to demolishing and rebuilding high cost |
Easily expand capacity and invest in installments |
Easily expand capacity and invest in installments |
|
|
Investment evaluation |
êêêê |
êêêêê |
êêêêê |
|
|
Operation |
Efficiency |
85%-94% |
94%-96% |
96% |
|
Investment evaluation |
êêê |
êêêê |
êêêêê |
|
|
Maintenance |
Maintenance |
Need to remove cables and internal structure, high maintenance costs, “modular type” detachable module maintenance，maintenance costs are medium |
The power module can be hot-swapped and replaced online, and the maintenance cost is low |
Monitoring bypass module and power module support online hot swap replacement, low maintenance cost |
|
Investment evaluation |
êêê |
êêêê |
êêêêê |
|
|
Overall investment evaluation |
êêê |
êêêê |
êêêêê |
|
